Ceiling Loudspeakers
C PRO 8 MKII
#82CPR208
Ceiling speaker. 40 W @ 8 Ohm. 40/20/10 W @ L100V. 8'' Woofer + 1'' Tweeter (rotatable).
C PRO 8 MKII is a two-way ceiling loudspeaker suitable for 70/100 V line or low impedance installations. It is composed of an 8 "loudspeaker and a 1" tweeter. It has a grid with magnets, facilitating its assembly. In addition, the cover of this can be painted, thus facilitating integration into any space. Once installed, the tweeter can be rotated to control directionality to enhance the audio experience.
Main information
- Rotatable tweeter.
- Grille with magnets.
- Low impedance and 70/100 V line.
- Paintable grid cover.
Product main measures (m)
0.28 x
0.28 x
0.11
| Type | Passive. 2 ways |
| Low Impedance Power | 40 W @ 8 Ohm |
| L100V Power | 40 W / 20 W / 10 W |
| LF Transducer | Woofer 8" |
| HF Transducer | Tweeter 1" |
| Frequency Range | 50 Hz - 20 KHz |
| Coverage | 100º x 60º |
| Sensitivity | 90 dB |
| Mounting diameter | 245 mm |
| Mounting depth | 100 mm |
| Fixation | 3 pivotes rotativos/ 3 rotating pivots |
| Material | Enclosure: ABS plastic; Grille: metal |
| Colour | Blanco (RAL9016) |
| Dimensions | Ø281 x 110 mm |
| Weight | 2.83 Kg |
| Length(m) | Width(m) | Height(m) | Weight(kg) | |
|---|---|---|---|---|
| Product | 0.28 | 0.28 | 0.11 | 2.83 |
| Box | 0.36 | 0.35 | 0.18 | 3.80 |
| Master Carton | 0.38 | 0.75 | 0.40 | 17.00 |
C PRO 8 MKII | Acoustic Simulator
Optimise your C PRO 8 MKII with our Acoustic Simulator
With this online tool you can quickly design your PA system, calculating how many speakers and amplifiers you need and where to place them.
